Tungsten carbide burrs for high performance, NON FERROUS, cylindrical shape with radius end WRC

Tungsten carbide high-performance burr NON-FERROUS cylindrical with radius end WRC dia. 06x16 mm shank dia. 6 mm non-ferrous metals

Item number:: 21105096
EAN:: 4007220221068

Technical information

Tungsten carbide high-performance burr NON-FERROUS cylindrical with radius end WRC dia. 06x16 mm shank dia. 6 mm non-ferrous metals

Cut: NON-FERROUS
Dia. external: 6 mm
Dia. shank: 6 mm
Length, cut: 16 mm
Length, total: 2,165
Length, total: 55 mm
RPM from, hard non-ferrous metals: 32000 RPM
RPM from, soft non-ferrous metals: 24000 RPM
RPM from, thermoplastics, fibre-reinforced plastics (GRP/CRP): 32000 RPM
RPM to, hard non-ferrous metals: 48000 RPM
RPM to, soft non-ferrous metals: 32000 RPM
RPM to, thermoplastics, fibre-reinforced plastics (GRP/CRP): 59000 RPM
Packaging unit: 1 piece

Description

PFERD has developed the NON-FERROUS cut for general-purpose use on non-ferrous metals and fibre-reinforced plastics. This cut is characterized by its high stock removal rate.

Cylindrical burr with radius end according to DIN 8032. Combination of cylindrical and ball-shaped geometries.

Advantages

Very good stock removal rate when used on non-ferrous metals such as brass and copper, plastics and fibre-reinforced plastics.
The highly accurate concentricity enables impactfree working without creating chatter marks. This considerably reduces wear on the tool and tool drive.

Recommendations for use

To prevent vibrations, place the tools on powerful drives with an elastically supported spindle wherever possible.
Observe the recommended rotational speeds.
To ensure costeffective use of burrs, use a higher rotational speed and cutting speed. Use burrs with a shank diameter of 6 mm with drives with a power output from 300 watts.

Materials that can be worked: Brass; Bronze; Copper; Fibre-reinforced thermosetting plastics (GRP, CRP); Hard non-ferrous metal; Plastics; Thermoplastics; Zinc

Applications: Cutting out holes; Deburring; Leveling; Milling; Milling out; Surface work; Work on weld seams

Drive types: Flexible shaft drive; Robot; Stationary machines; Straight grinder; Tool machine
